Our researchers have developed a method for the selective growth of single carbon nanotubes (CNT) on the tip apex of a conventional cantilever. Selective CNT growth is established by coating the backside of a cantilever, having a through-hole at a tip apex, with a catalyst material followed by a cover layer. The exposed catalyst at the bottom of the hole at the apex of the cantilever induces growth of a single CNT at this location.
Carbon nanotube (CNT) probes have become an attractive alternative to AFM cantilevers. The CNT probe not only offers extraordinary nanometer scale resolution but is also robust, due to its high strength and the ability to retain structural integrity even after deformation within its elastic limit. Carbon nanotube probes known in the art are provided either by manual attachment of a carbon nanotube to the tip of the AFM cantilever or by growing a carbon nanotube through a lithography and chemical vapor deposition process from the ends of the silicon tip of the AFM probe. The process of manually attaching carbon nanotubes to the tip of an AFM is time consuming and selects against the smallest nanotubes, limiting the quality of tips.
- High aspect ratio
- High strength
- Extraordinary nanometer scale resolution
Schematic of CNT growth process from NSOM probe
